グライダーのフライトログに使用される.igcファイルの解説

グライダーなどのフライトログに使われる.igcファイルについて解説する

スポンサーリンク

.igcファイルとは

.igcファイルとは,IGC(International Gliding Commission)によって定められたグライダーなどの飛行を記録するためのテキストファイルの形式である

↓IGCについて

IGC-approved Flight Recorders
Each type of IGC Flight Recorder has an IGC-approval document that gives details of the Recorder, its hardware, internal...
IGC (file format) - Wikipedia

↓公式ドキュメント

[PDF] igc_fr_specification_with_al8_2023-2-1.pdf (1366 KB)
(p.20 Appendix A – The IGC Data File Standard 以降が参考になる)

↓英語の解説(有志)

IGC FILE FORMAT REFERENCE AND DEVELOPERS' GUIDE - Ian Forster-Lewis

この記事では,.igcファイルの中身の解読方法について説明する

.igcファイルの概要とrecordの構成

実際の.igcファイルはこんな感じ

AXNA9AD179D6D6F04DDD95474658245E6D4F
HFDTEDATE:180223,01
HFPLTPILOTINCHARGE:mtkbirdman
HFCM2CREW2:NIL
HFGTYGLIDERTYPE:G103a Twin Astir II
HFGIDGLIDERID:JA9999
HFDTMGPSDATUM:WGS84
HFRFWFIRMWAREVERSION:2.8.1+1647
HFRHWHARDWAREVERSION:Apple iPhone,Ios 16.2
HFFTYFRTYPE:Naviter,SeeYou Navigator
HFGPSRECEIVER:Unknown,Internal,0,0
HFPRSPRESSALTSENSOR:Unknown,Internal,0
HFALGALTGPS:ELL
HFALPALTPRESSURE:ISA
HFCIDCOMPETITIONID:NKN
HFCCLCOMPETITIONCLASS:NKN
HFTZNTIMEZONE:9.0
J020810WDI1113WSP
LXNA::VEHICLE:0
LXNA::LOGSTART,GSP,VARIO
LXNA::PHASE:onGround
E013830ATS102415
B0138300000000N00000000EV-004400000
B0138320000000N00000000EV-004400000
B0138340000000N00000000EV-004400000
B0138360000000N00000000EV-004400000
B0138370000000N00000000EV-004400000
B0138390000000N00000000EV-004400000
B0138410000000N00000000EV-004400000
B0138430000000N00000000EV-004400000
B0138450000000N00000000EV-004400000
B0138470000000N00000000EV-004400000
B0138490000000N00000000EV-004400000
B0138510000000N00000000EV-004400000
B0138520000000N00000000EV-004400000
B0138540000000N00000000EV-004400000
B0138560000000N00000000EV-004400000
B0138580000000N00000000EV-004400000
B0139000000000N00000000EV-004400000
B0139020000000N00000000EV-004400000
B0139040000000N00000000EV-004400000
B0139060000000N00000000EV-004400000
B0139080000000N00000000EV-004400000
B0139090000000N00000000EV-004400000
B0139110000000N00000000EV-004400000
B0139130000000N00000000EV-004400000
B0139150000000N00000000EV-004400000
B0139170000000N00000000EV-004500000
B0139190000000N00000000EV-004500000
B0139210000000N00000000EV-004500000
B0139230000000N00000000EV-004500000
B0139240000000N00000000EV-004500000
B0139260000000N00000000EV-004400000
B0139280000000N00000000EV-004400000
B0139300000000N00000000EV-004400000
B0139320000000N00000000EV-004400000
B0139340000000N00000000EV-004400000
B0139360000000N00000000EV-004400000
B0139380000000N00000000EV-004400000
B0139400000000N00000000EV-004400000
B0139410000000N00000000EV-004400000
B0139430000000N00000000EV-004400000
B0139450000000N00000000EV-004400000
B0139470000000N00000000EV-004400000
B0139490000000N00000000EV-004400000
B0139510000000N00000000EV-004400000
B0139530000000N00000000EV-004400000
B0139554901391N00233687EA0011900119
B0139564901391N00233686EA0011900119
B0139574901391N00233684EA0011900119
LXNA::PHASE:takingOff
B0139584901391N00233676EA0011900119
B0139594901392N00233665EA0011900119
B0140004901393N00233653EA0011900119
B0140014901394N00233636EA0012000119
B0140024901393N00233618EA0012000120
B0140034901393N00233600EA0012200121
B0140044901393N00233584EA0012600123
B0140054901393N00233567EA0013100126
B0140064901393N00233551EA0013900129
B0140074901392N00233540EA0014900132
LXNA::PHASE:onTow
B0140084901393N00233528EA0016000136
B0140094901392N00233518EA0017400140
B0140104901391N00233506EA0019000146
B0140114901390N00233495EA0020700151
B0140124901390N00233484EA0022400159
B0140134901385N00233469EA0024200168
B0140144901381N00233458EA0025900180
B0140154901380N00233441EA0027600196
B0140164901380N00233378EA0030900150
B0140174901379N00233361EA0032400166
B0140184901379N00233343EA0033900181
B0140194901383N00233325EA0035300223
B0140204901358N00233292EA0036700133
B0140214901360N00233273EA0038000133
B0140224901363N00233255EA0039200136
B0140234901368N00233236EA0040300141
B0140244901373N00233216EA0041500145
B0140254901385N00233199EA0042600192
B0140264901395N00233182EA0043600236
B0140274901365N00233191EA0044700131
B0140284901369N00233170EA0045700131
B0140294901391N00233143EA0046700229
B0140304901410N00233119EA0047600304
B0140314901377N00233111EA0048400137
B0140324901378N00233095EA0049100130
B0140334901405N00233074EA0050200234
B0140344901436N00233075EA0050500372
B0140354901440N00233057EA0050700374
B0140364901444N00233039EA0050800378
B0140374901449N00233021EA0050800382
B0140384901453N00233004EA0050700385
B0140394901458N00232988EA0050700386
B0140404901462N00232972EA0050600389
B0140414901466N00232956EA0050600391
B0140424901471N00232939EA0050500394
B0140434901511N00232912EA0050500265
B0140444901515N00232898EA0050400310
B0140454901454N00232844EA0050400141
B0140464901467N00232833EA0050300132
B0140474901486N00232826EA0050200231
B0140484901498N00232816EA0050100304
LXNA::PHASE:soaring
B0140494901488N00232799EA0050000152
B0140504901492N00232782EA0049900135
B0140514901504N00232770EA0049600227
B0140524901514N00232754EA0049500293
B0140534901511N00232732EA0049400285
B0140544901515N00232715EA0049200285
B0140554901499N00232683EA0049100126
B0140564901504N00232666EA0049100126
B0140574901526N00232660EA0049000221
B0140584901540N00232650EA0048900291
B0140594901535N00232643EA0048800150
B0141004901540N00232620EA0048800161
B0141014901554N00232614EA0048700298
B0141024901539N00232564EA0048700120
B0141034901561N00232552EA0048600120
B0141044901580N00232545EA0048500166
B0141054901593N00232535EA0048500206
B0141064901602N00232521EA0048400204
B0141074901616N00232512EA0048200239
B0141084901630N00232507EA0048100268
B0141094901643N00232498EA0047800267
B0141104901658N00232492EA0047700266
B0141114901673N00232491EA0047600265
B0141124901688N00232492EA0047600264
B0141134901704N00232495EA0047500263
B0141144901718N00232504EA0047400262
B0141154901768N00232410EA0047400118
B0141164901774N00232428EA0047300116
B0141174901780N00232442EA0047200116
B0141184901786N00232457EA0047200115
B0141194901789N00232476EA0047100116
B0141204901794N00232493EA0047100115
B0141214901799N00232509EA0047100115
B0141224901804N00232526EA0047100115
B0141234901808N00232543EA0047100115
K014123054846
B0141244901812N00232556EA0047100115
B0141254901815N00232572EA0047100115
B0141264901819N00232587EA0047100115
B0141274901821N00232601EA0047000115
B0141284901816N00232636EA0047000139
B0141294901812N00232659EA0047000136
B0141304901824N00232683EA0047000133
B0141314901826N00232707EA0046900131
B0141324901829N00232732EA0046900130
B0141334901831N00232754EA0046800128
B0141344901833N00232777EA0046700126
B0141354901835N00232797EA0046700125
B0141364901830N00232742EA0046600112
B0141374901831N00232758EA0046500111
B0141384901832N00232772EA0046500111
B0141394901832N00232788EA0046400111
B0141404901833N00232803EA0046400111
B0141414901835N00232817EA0046300112
B0141424901836N00232833EA0046300112
B0141434901837N00232847EA0046300112
B0141444901838N00232860EA0046200113
B0141454901839N00232877EA0046200112
B0141464901838N00232892EA0046200112
B0141474901839N00232906EA0046100112
B0141484901831N00232922EA0046100111
B0141494901832N00232938EA0046000110
B0141504901833N00232952EA0045900110
B0141514901834N00232967EA0045800109
B0141524901835N00232984EA0045700110
B0141534901836N00232999EA0045600110
B0141544901837N00233013EA0045600110
B0141554901838N00233028EA0045500110
B0141564901864N00233039EA0045400110
B0141574901865N00233054EA0045400112
B0141584901866N00233067EA0045300113
B0141594901867N00233083EA0045300114
B0142004901869N00233096EA0045200115
B0142014901870N00233110EA0045200115
B0142024901849N00233128EA0045200115
B0142034901849N00233142EA0045100115
B0142044901850N00233156EA0045000115
B0142054901851N00233172EA0044900114
B0142064901851N00233187EA0044800114
B0142074901853N00233200EA0044700114
B0142084901854N00233216EA0044700114
B0142094901855N00233229EA0044600115
B0142104901856N00233244EA0044500116
B0142114901856N00233259EA0044500117
B0142124901857N00233272EA0044500117
B0142134901858N00233288EA0044400117
B0142144901858N00233301EA0044400117
B0142154901859N00233316EA0044400116
B0142164901861N00233330EA0044400116
B0142174901866N00233343EA0044300116
B0142184901871N00233357EA0044200115
B0142194901878N00233369EA0044000115
B0142204901886N00233379EA0043900115
B0142214901895N00233389EA0043800116
B0142224901905N00233398EA0043500117
B0142234901914N00233406EA0043400117
B0142244901924N00233413EA0043400117
B0142254901935N00233415EA0043300118
B0142264901946N00233418EA0043300118
B0142274901958N00233421EA0043200119
B0142284901970N00233421EA0043200119
B0142294901982N00233418EA0043100119
B0142304901994N00233416EA0043100119
B0142314902005N00233412EA0043000119
B0142324902016N00233405EA0043000119
B0142334902027N00233397EA0042900119
B0142344902037N00233390EA0042900119
B0142354902047N00233381EA0042800119
B0142364902057N00233371EA0042700120
B0142374902066N00233361EA0042600118
B0142384902074N00233348EA0042600118
B0142394902081N00233334EA0042500118
B0142404902088N00233317EA0042400117
B0142414902092N00233301EA0042300116
B0142424902095N00233284EA0042200115
B0142434902098N00233269EA0042100115
B0142444902099N00233252EA0042000114
B0142454902099N00233235EA0041900115
B0142464902099N00233217EA0041800115
B0142474902099N00233199EA0041700115
B0142484902098N00233182EA0041700115
B0142494902096N00233164EA0041600115
B0142504902095N00233146EA0041600114
B0142514902093N00233129EA0041500114
B0142524902083N00233112EA0041400114
B0142534902083N00233096EA0041400115
B0142544902082N00233078EA0041300115
B0142554902082N00233062EA0041300115
B0142564902081N00233045EA0041200115
B0142574902082N00233028EA0041200115
B0142584902083N00233011EA0041200115
B0142594902083N00232991EA0041100114
B0143004902083N00232973EA0041000113
B0143014902083N00232956EA0041000112
B0143024902084N00232938EA0040900112
B0143034902084N00232920EA0040800111
B0143044902083N00232903EA0040700110
B0143054902083N00232886EA0040600110
B0143064902082N00232869EA0040500110
B0143074902082N00232852EA0040400110
B0143084902083N00232835EA0040300110
B0143094902083N00232820EA0040200110
B0143104902084N00232803EA0040100110
B0143114902085N00232787EA0040000110
B0143124902085N00232771EA0040000111
B0143134902085N00232757EA0039900110
B0143144902085N00232743EA0039900111
B0143154902084N00232728EA0039800111
B0143164902083N00232715EA0039800111
B0143174902082N00232700EA0039700111
B0143184902080N00232684EA0039700110
B0143194902079N00232669EA0039600109
B0143204902078N00232653EA0039500109
B0143214902077N00232636EA0039400109
B0143224902079N00232621EA0039300110
B0143234902054N00232611EA0039200110
B0143244902043N00232598EA0039100110
B0143254902033N00232587EA0039100110
B0143264902018N00232579EA0039000110
B0143274902003N00232566EA0039000111
B0143284901988N00232565EA0038900111
B0143294901975N00232567EA0038900111
B0143304901966N00232548EA0038800111
B0143314901955N00232540EA0038800111
B0143324901945N00232535EA0038800110
B0143334901934N00232528EA0038700109
B0143344901924N00232525EA0038700108
B0143354901890N00232582EA0038600107
B0143364901880N00232591EA0038500106
B0143374901870N00232600EA0038400105
B0143384901862N00232616EA0038100105
B0143394901853N00232630EA0038000105
B0143404901846N00232645EA0037900105
B0143414901843N00232666EA0037800106
B0143424901835N00232681EA0037700106
B0143434901849N00232695EA0037700107
B0143444901851N00232709EA0037600107
B0143454901841N00232727EA0037600109
B0143464901841N00232745EA0037600109
B0143474901842N00232760EA0037500110
B0143484901843N00232772EA0037500110
B0143494901844N00232787EA0037400110
B0143504901846N00232800EA0037400110
B0143514901847N00232815EA0037300111
B0143524901848N00232829EA0037300111
B0143534901849N00232842EA0037300111
B0143544901850N00232857EA0037200110
B0143554901851N00232869EA0037200110
B0143564901835N00232886EA0037200111
B0143574901835N00232899EA0037000111
B0143584901836N00232913EA0037000112
B0143594901837N00232928EA0036900112
B0144004901837N00232941EA0036800112
B0144014901833N00232956EA0036800111
B0144024901834N00232969EA0036700112
B0144034901835N00232984EA0036600112
B0144044901836N00232997EA0036500112
B0144054901838N00233012EA0036400112
B0144064901838N00233026EA0036300112
B0144074901864N00233038EA0036200113
B0144084901865N00233051EA0036100113
B0144094901866N00233065EA0036000113
B0144104901867N00233081EA0036000112
B0144114901867N00233094EA0035900111
B0144124901865N00233110EA0035800109
B0144134901864N00233125EA0035600107
B0144144901821N00233144EA0035500106
B0144154901815N00233158EA0035300105
B0144164901807N00233172EA0035100105
B0144174901798N00233183EA0034600106
B0144184901787N00233193EA0034400106
B0144194901774N00233200EA0034300107
B0144204901762N00233205EA0034200107
B0144214901748N00233206EA0034200107
B0144224901735N00233202EA0034200108
B0144234901721N00233200EA0034100107
B0144244901708N00233192EA0034100107
K014424054846
B0144254901696N00233183EA0034000107
B0144264901684N00233174EA0034000107
B0144274901676N00233160EA0033900107
B0144284901669N00233146EA0033800107
B0144294901665N00233129EA0033700107
B0144304901663N00233116EA0033600107
B0144314901664N00233101EA0033500108
B0144324901668N00233089EA0033500108
B0144334901673N00233078EA0033500108
B0144344901680N00233067EA0033400107
B0144354901687N00233059EA0033400109
B0144364901696N00233053EA0033200110
B0144374901706N00233047EA0033100110
B0144384901718N00233045EA0033000111
B0144394901728N00233044EA0032900111
B0144404901740N00233046EA0032800112
B0144414901752N00233049EA0032700112
B0144424901762N00233056EA0032700112
B0144434901772N00233062EA0032600112
B0144444901781N00233071EA0032500112
B0144454901789N00233078EA0032500113
B0144464901795N00233089EA0032400112
B0144474901800N00233101EA0032300112
B0144484901804N00233113EA0032200111
B0144494901807N00233128EA0032100111
B0144504901810N00233143EA0032000111
B0144514901811N00233156EA0031900110
B0144524901812N00233171EA0031700110
B0144534901813N00233184EA0031600111
B0144544901813N00233200EA0031500111
K014454017794
B0144554901814N00233215EA0031300111
B0144564901814N00233228EA0031200112
B0144574901814N00233244EA0031100113
B0144584901815N00233257EA0031100114
B0144594901817N00233271EA0031100114
B0145004901819N00233287EA0031100113
B0145014901822N00233301EA0031100113
B0145024901827N00233315EA0031100112
B0145034901833N00233326EA0031000112
B0145044901842N00233337EA0030900113
B0145054901851N00233346EA0030700114
B0145064901861N00233354EA0030600114
B0145074901872N00233360EA0030500115
B0145084901884N00233362EA0030500116
B0145094901896N00233362EA0030400118
B0145104901908N00233359EA0030400119
B0145114901920N00233352EA0030400119
B0145124901930N00233344EA0030400119
B0145134901940N00233334EA0030400119
B0145144901948N00233319EA0030400118
B0145154901954N00233306EA0030400118
B0145164901958N00233290EA0030300118
B0145174901961N00233273EA0030200117
B0145184901961N00233257EA0030100116
B0145194901960N00233239EA0030000114
B0145204901956N00233224EA0029900114
K014520010880
B0145214901951N00233208EA0029700114
B0145224901944N00233191EA0029600113
B0145234901936N00233179EA0029400113
B0145244901927N00233167EA0029300113
B0145254901916N00233157EA0029200114
B0145264901905N00233149EA0029200115
B0145274901892N00233144EA0029100115
B0145284901880N00233138EA0029100115
B0145294901867N00233135EA0029100116
B0145304901854N00233134EA0029000116
B0145314901841N00233133EA0029000116
B0145324901827N00233135EA0029000114
B0145334901813N00233139EA0029000112
B0145344901800N00233146EA0029000110
B0145354901788N00233155EA0028900110
B0145364901777N00233167EA0028700110
B0145374901769N00233181EA0028500111
B0145384901761N00233197EA0028100110
B0145394901756N00233212EA0028000110
B0145404901752N00233229EA0027900109
B0145414901751N00233246EA0027800109
B0145424901750N00233263EA0027800109
B0145434901749N00233281EA0027600110
B0145444901750N00233298EA0027500111
B0145454901751N00233315EA0027400112
B0145464901752N00233330EA0027400113
K014546353345
B0145474901753N00233346EA0027300114
B0145484901754N00233362EA0027300116
B0145494901755N00233378EA0027300117
B0145504901756N00233394EA0027400119
B0145514901757N00233408EA0027500118
B0145524901759N00233424EA0027500117
B0145534901760N00233440EA0027500115
B0145544901762N00233454EA0027500115
B0145554901764N00233469EA0027500114
B0145564901766N00233486EA0027400113
B0145574901767N00233501EA0027300114
B0145584901769N00233515EA0027000114
B0145594901770N00233531EA0026900114
B0146004901770N00233548EA0026800113
B0146014901770N00233564EA0026700113
B0146024901771N00233581EA0026600112
B0146034901772N00233596EA0026500110
B0146044901773N00233613EA0026400109
B0146054901774N00233630EA0026300107
B0146064901773N00233649EA0026100105
B0146074901776N00233666EA0025900103
B0146084901781N00233683EA0025700101
B0146094901787N00233701EA0025500100
B0146104901792N00233719EA0025300099
B0146114901797N00233736EA0025000098
B0146124901802N00233753EA0024800099
B0146134901805N00233772EA0024600099
B0146144901807N00233791EA0024500102
B0146154901809N00233809EA0024500106
B0146164901788N00233835EA0024400110
B0146174901792N00233852EA0024400112
B0146184901800N00233869EA0024400114
B0146194901803N00233886EA0024600116
B0146204901807N00233898EA0024600116
B0146214901786N00233925EA0024700115
B0146224901787N00233942EA0024700115
B0146234901789N00233958EA0024700114
B0146244901791N00233973EA0024600113
B0146254901792N00233990EA0024500113
B0146264901792N00234008EA0024400113
B0146274901792N00234025EA0024200112
B0146284901792N00234043EA0024100112
B0146294901793N00234061EA0023900112
B0146304901793N00234078EA0023700112
B0146314901793N00234095EA0023600113
B0146324901792N00234113EA0023400114
B0146334901792N00234129EA0023300116
B0146344901791N00234146EA0023300117
B0146354901776N00234156EA0023200118
B0146364901773N00234172EA0023200117
B0146374901772N00234195EA0023200115
B0146384901773N00234212EA0023200113
B0146394901773N00234229EA0023200111
B0146404901772N00234251EA0022900109
B0146414901774N00234267EA0022700108
B0146424901775N00234282EA0022500107
B0146434901775N00234298EA0022400107
B0146444901773N00234312EA0022200108
B0146454901774N00234327EA0022100108
B0146464901763N00234338EA0022000109
B0146474901748N00234349EA0022000110
B0146484901734N00234357EA0022000112
B0146494901720N00234364EA0022000114
B0146504901705N00234370EA0022000114
B0146514901690N00234374EA0022000115
B0146524901676N00234380EA0021900116
B0146534901661N00234384EA0021900117
B0146544901646N00234388EA0021800118
B0146554901631N00234391EA0021700119
B0146564901617N00234396EA0021600120
B0146574901602N00234399EA0021600119
B0146584901587N00234402EA0021600120
B0146594901572N00234407EA0021600120
B0147004901557N00234410EA0021500121
B0147014901542N00234412EA0021400120
B0147024901527N00234412EA0021300119
B0147034901513N00234410EA0021200119
B0147044901499N00234408EA0021100119
B0147054901485N00234401EA0021000119
B0147064901473N00234393EA0020800119
B0147074901462N00234383EA0020800119
B0147084901453N00234372EA0020700120
B0147094901445N00234358EA0020700121
B0147104901439N00234346EA0020700119
B0147114901437N00234330EA0020400115
B0147124901436N00234315EA0020100111
B0147134901435N00234299EA0019700109
B0147144901434N00234283EA0019200108
B0147154901432N00234267EA0018600107
B0147164901424N00234251EA0018300106
B0147174901423N00234236EA0017900104
B0147184901423N00234220EA0017600102
B0147194901423N00234203EA0017300101
B0147204901422N00234185EA0017000100
B0147214901421N00234169EA0016700100
B0147224901421N00234152EA0016300100
B0147234901420N00234137EA0015700102
B0147244901420N00234121EA0015400102
B0147254901420N00234104EA0015200102
B0147264901419N00234089EA0015000102
B0147274901418N00234074EA0014900100
B0147284901418N00234058EA0014700099
B0147294901417N00234041EA0014400098
B0147304901416N00234025EA0014200097
B0147314901415N00234009EA0013900096
B0147324901413N00233994EA0013600094
B0147334901412N00233978EA0013300093
B0147344901411N00233961EA0013000092
B0147354901410N00233945EA0012600093
B0147364901409N00233930EA0012300094
B0147374901408N00233915EA0012000096
B0147384901407N00233899EA0011700097
B0147394901406N00233886EA0011500099
B0147404901407N00233871EA0011400106
B0147414901407N00233859EA0011300109
B0147424901408N00233847EA0011300113
B0147434901408N00233835EA0011300115
B0147444901408N00233826EA0011300117
B0147454901407N00233816EA0011400118
B0147464901406N00233806EA0011400119
B0147474901405N00233798EA0011500120
B0147484901403N00233789EA0011500120
B0147494901403N00233781EA0011500121
B0147504901401N00233773EA0011500121
B0147514901400N00233766EA0011600121
B0147524901399N00233761EA0011600122
B0147534901398N00233755EA0011600122
B0147544901397N00233748EA0011600122
B0147554901397N00233743EA0011700122
B0147564901396N00233737EA0011700121
B0147574901396N00233733EA0011700121
B0147584901395N00233728EA0011700121
B0147594901394N00233724EA0011700121
B0148004901394N00233719EA0011700120
B0148014901393N00233715EA0011800120
B0148024901393N00233710EA0011800120
B0148034901392N00233708EA0011800120
B0148044901391N00233704EA0011800120
B0148054901391N00233701EA0011800120
B0148064901391N00233699EA0011800120
B0148074901391N00233697EA0011800119
B0148084901390N00233694EA0011800119
B0148094901390N00233693EA0011800119
B0148104901390N00233692EA0011800119
B0148114901390N00233691EA0011800119
B0148124901391N00233691EA0011800119
B0148134901391N00233690EA0011800119
B0148144901391N00233689EA0011800119
B0148154901391N00233689EA0011800119
B0148164901391N00233687EA0011800119
B0148174901391N00233687EA0011800119
B0148184901391N00233687EA0011800119
B0148194901390N00233687EA0011800118
B0148204901390N00233687EA0011800119
B0148214901390N00233687EA0011800119
LXNA::LOGSTOP
LXNA::PHASE:onGround
G0089F458A95684AE250AC7B8DA396BC8E433EE2D84F50902C8641C5BD35688A7952D56
G798F3A2F480A436464D87A7F556F35AAA7D09A5C7E742970CEF5D264A5A8
LXCM::TKOFFLAND:1,20230218014008,20230218014821
LXCM::TKOFFLANDALT:1,90,48
LXCM::SOARINGBEGIN:1,20230218014049,430
LXCM::OPT:1,3,6664,5,7348,5,7348
LXCM::TRIANGLE:1,FAI_NO,6632,-16384
LXCM::FLTSTAT1:1,14.91,-0.81,21.30,438,261,31.85
LXCM::FLTSTAT2:1,20230218014036,20230218014027
LXCM::FLTVARIO:1,20,18.44,20230218014013,-5.56,20230218014715
LXCM::ENDINFO

.igcファイルはA recordからL recordまでの12種類の記録項目があり,各行の1文字目を見ればその行が何を記録しているか判別することができる

A~Lまでのrecordで記録される内容は以下の通り

record type説明
AFlight Record(FR)の製造者とFRのシリアル番号
B毎時取得する基本データ(時刻,緯度/経度,高度)
C
D
Eイベント
FB recordに使用される衛星の情報
G記録の改竄などを防止するセキュリティ記録
Hファイルのヘッダー
IB recordに追加して取得するデータの設定
JK recordで取得するデータの設定
KBよりも低い頻度で取得する情報
Lコメントアウトみたいなもの

基本的にパイロットが知りたいのはB recordの情報で,それ以外のrecordは別に無視しても構わない

上記のレコードは,通常以下のような順番でファイルに記述される

A - Flight Record(FR)の製造者とFRのシリアル番号 (必ず1行目)
H - ファイルのヘッダー (2行目以降に記述される)
I - B recordに追加して取得するデータの設定(任意)
J - K recordで取得するデータの設定(任意)
C, D - ?(任意)
F - B recordに使用される衛星の情報

B - 毎時取得する基本データ(時刻,緯度/経度,高度)
B - 毎時取得する基本データ(時刻,緯度/経度,高度)
:
E - イベント(任意)
B - 毎時取得する基本情報(時刻,緯度/経度,高度)
K - J recordで設定されたデータ(デフォルトで20秒間隔)
B - 毎時取得する基本情報(時刻,緯度/経度,高度)
:

L - コメントアウト(任意)
G - セキュリティ記録
L - 飛行終了時に追加されるデータ

なお,.igcファイルで用いられる時刻はUTC(協定世界時)である

まずは1番重要なB recordから説明する

それ以外はおまけみたいなもんである

B record

B0140344901436N00233075EA0050500372

B recordは以下のデータで構成されている

B HHMMSS DDMMmmmN/S DDDMMmmmE/W A/V PPPPP GGGGG

  • B:B record
  • HHMMSS:UTCによる時刻
  • DDMMmmmN/S:緯度
  • DDDMMmmmE/W:経度
  • A/V:3次元データ/2次元データ
  • PPPPP:ISA 1013.25 HPaに対する気圧高度 [m]
  • GGGGG:WGS84楕円体からの高度 [m]

上記の例のB record「B 014034 4901436N 00233075E A 00505 00372」は以下のような意味になる

  • B:B recordとして記録される
  • 014034:1時40分34秒(UTC)
  • 4901436N:北緯49度01.436分
  • 00233075E:東経2度33.075分
  • A:3次元データ
  • 00505:気圧高度505m
  • 00372:WGS84楕円体からの高度372m
igc_fr_specification_with_al8_2023-2-1.pdf (1366 KB) p.32

ファイル名

2023-02-22-XNA-9AD179D6D6F04DDD95474658245E6D4F-01.igc

ファイル名は以下のデータで構成されている

YYYY-MM-DD-MMM-XXXXXX-01.igc

  • YYYY:年
  • MM:月
  • DD:日
  • MMM:製造者コード
  • XXXXXX:固有のFRシリアルID
  • 01:その日のフライトの通し番号

例にあげたログは「See you Navigator」のiPhoneアプリで記録したものなので,製造者はXNA(Naviter Hyper)になっている

Approved loggers | WeGlide Docs
Approval levels for different flight track loggers and troubleshooting of common issues to get your glider flight valid.
‎SeeYou Navigator
‎Want to fly light-weight? Just going for a quick flight or two and don’t want all the heavy equipment? Install SeeYou N...

A record

AXNA9AD179D6D6F04DDD95474658245E6D4F

A recordは以下のデータで構成されている

A MMM XXXXXX

  • A:A record
  • MMM:製造者コード
  • XXXXXX:固有のFRシリアルID

H record

HFDTEDATE:220223,01
HFPLTPILOTINCHARGE:mtkbirdman
HFCM2CREW2:NIL
HFGTYGLIDERTYPE:G103a Twin Astir II
HFGIDGLIDERID:JA9999
HFDTMGPSDATUM:WGS84
HFRFWFIRMWAREVERSION:2.8.1+1647
HFRHWHARDWAREVERSION:Apple iPhone,Ios 16.2
HFFTYFRTYPE:Naviter,SeeYou Navigator
HFGPSRECEIVER:Unknown,Internal,0,0
HFPRSPRESSALTSENSOR:Unknown,Internal,0
HFALGALTGPS:ELL
HFALPALTPRESSURE:ISA
HFCIDCOMPETITIONID:NKN
HFCCLCOMPETITIONCLASS:NKN
HFTZNTIMEZONE:9.0

H recordは以下のデータで構成されている

H F/O CCC CCCCCC: text strings

  • H:H record
  • F/O:データソース(F:Flight record,O:Others)
  • CCC:項目の3文字略称(TLC:Three letter Code)
  • CCCCCC:項目名(文字数任意)
  • text strings:任意の文字列

大事そうなものを説明する

H record説明
H F DTE DATE: DDMMYY, NNフライトの日付,通し番号
H F PLT PILOT IN CHARGE: TEXT STRINGパイロットの名前
H F GTY GLIDER TYPE: TEXT STRING機種
H F GID GLIDER ID: TEXT STRING機体の登録番号
H F DTM GPS DATUM: WGS84GPSに使用している測地系
H F RHW HARDWARE VERSION: TEXT STRINGGPSに使用した機器
H F FTY FR TYPE: MANUFACTURERS NAME,FR MODEL NAME製造者名,Flight recordモデル

I record / J record

J020810WDI1113WSP

I record/ J recordは以下のデータで構成されている

I/J NN SS FF CCC ...

  • I/J:I record / J record
  • NN:追加で記録するデータの数
  • SS:追加データの各行における開始位置
  • FF:追加データの各行における終了位置
  • CCC:追加されるデータ項目の3文字略称(TLC:Three letter Code)

上記の例のJ record「J 02 08 10 WDI 11 13 WSP」は以下のような意味になる

  • J:K recordとして記録されるデータを設定する
  • 02:K recordに追加で2つのデータを記録する
  • 08 10 WDI:8文字目から10文字目にWDI(Wind DIrection)を記録する
  • 11 13 WSP:11文字目から13文字目にWSP(Wind SPeed)を記録する

3文字略称(TLC:Three letter Code)については igc_fr_specification_with_al8_2023-2-1.pdf (1366 KB) のpp.36-39に一覧表がある

igc_fr_specification_with_al8_2023-2-1.pdf (1366 KB) p.38

E record

E013830ATS102415

E recordは以下のデータで構成されている

E HH MM SS CCC

  • E:E record
  • HH:時
  • MM:分
  • SS:秒
  • CCC:イベントの3文字略称(TLC:Three letter Code)

上記の例のE record「E 01 38 30 ATS 102415」は,Flight recorderに接続された表示装置の高度計の設定が01時38分30秒に1024.15hPaに変更されたことを示している

igc_fr_specification_with_al8_2023-2-1.pdf (1366 KB) p.36

K record

K014123054846

K recordは以下のデータで構成されている

K HH MM SS OPTIONAL

  • K:K record
  • HH:時
  • MM:分
  • SS:秒
  • OPTIONAL:J recordで設定されたデータ

おわりに

グライダーなどのフライトログに使われる.igcファイルについて解説した

↓フライトログ記録アプリ

SeeYou Navigator – Naviter.com
‎SeeYou Navigator
‎Want to fly light-weight? Just going for a quick flight or two and don’t want all the heavy equipment? Install SeeYou N...

↓関連記事

グライダー
質問・感想・意見などあれば気軽にTwitterのDMかコメントお願いします!
スポンサーリンク
mtk_birdman's blog

コメント
